The Revo X Series laser welders deliver powerful, precise Nd:YAG welding for jewelry and industrial applications. Designed for long production cycles, they offer over 15 hours of continuous operation, advanced cooling, and exceptional stability even on difficult metals like silver and platinum. A wide ergonomic chamber, 7″ touch interface, Leica optics, and Wi‑Fi connectivity make the Revo X Series fast, intuitive, and reliable. Choose from Revo X, Revo X², and Revo X+ to match your power, speed, and workflow needs.
- High‑performance Nd:YAG welding with stable results on all metals
- 8‑liter dual‑radiator cooling for long continuous duty
- Large chamber with removable bottom for oversized pieces
- 7″ capacitive touchscreen with presets and job storage
- Leica 45° stereo microscope with 10× zoom
- Wi‑Fi + telemetry for remote diagnostics
- IUVAPS™ sanitizing system for a cleaner internal environment
| Spec | Revo X | Revo X² | Revo X+ |
|---|---|---|---|
| Crystal | Nd:YAG 1064 nm | Nd:YAG 1064 nm | Nd:YAG 1064 nm ×2 |
| Pulse Power | 240 J | 240 J | 280 J |
| Peak Power | 10 kW | 10 kW | 12 kW |
| Avg. Power | 90 W | 120 W | 150 W |
| Frequency | 0–40 Hz | 0–40 Hz | 0–40 Hz |
| Focal Ø | 0.1–2 mm | 0.1–2 mm | 0.2–2 mm |
| Power Supply | 230 VAC ±10%, 1P+N+PE, 50/60 Hz 2.2 kW (X & X+) / 3.6 kW (X²) |
||
| Cooling | Forced air + 8 L tank, dual radiator | ||
| Weight | 65 kg | 75 kg | 75 kg |
