F3 CEIA CRUCIBLE

F3 CEIA CRUCIBLE (ARG122V)

Crucible F3 has a Capacity of :  3Kilo of Pure Gold and 2Kilo of 18Kt Gold



Crucible Induction Melting F3 Crucible for CEIA Induction Melter Model F3D.  Crucible comes complete with graphite liner with the ceramic outer container shell joined together with High Temperature refractory cement.  This crucible is designed to be used with the Induction Melter made by CEIA



SPECIFICATIONS:



Total Height:    5.53″ / 140mm



Height to Bottom Ceramic Lip:  4.73″ / 120.2mm



Ceramic Shell Outer Diameter:   2.76″ / 70.1mm



Ceramic Shell OD Lip Diameter:   3.12″ / 79.4mm



Ceramic Lip Thickness:   0.410″ / 10.4mm



Inside Diameter of Graphite:   1.17″ / 42.2mm



Interior Depth of Graphite:  4.64″ / 117.9mm



Graphite Thickness:   0.394″ / 10.0mm



Crucible Weight:   1Lb .7oz. /  0.66 Kg.
